The Challenge
- Converting an existing old residential structure into a fully functional, modern commercial retail space.
- Translating complex architectural design provided in PDF format into a comprehensive 3D Revit model.
- Managing the time intensive process of generating high quality CGI rendering and detailed construction drawings.
- Ensuring meticulous attention to detail while modeling both the existing and the proposed renovation phases.
- Coordinating closely with the construction team to maintain a strict renovation schedule and prevent delays.
- Balancing the technical requirements of retail fit outs with the structural constraints of older buildings.
The Solution
- Developed an accurate 3DRevit model to visualize the transition from the existing house to the new superstore.
- Utilized advanced rendering to produce quality CGI imagery for design and marketing.
- Comprehensive fit out and shop drawings to guide the interior commercial installation.
- Detailed construction schedules to help the on site team manage the renovation timeline effectively.
- A structured workflow to ensure precise data extraction from PDF sources into the BIM environment.
- Facilitate regular communication between architects and contractors to align design intent with construction execution.
